GIGABYTE B550M DS3H AM4 AMD Micro-ATX Motherboard
Feature | Specification |
---|---|
Socket | AM4 (AMD Ryzen 3000/4000/5000 Series) |
Chipset | AMD B550 |
Memory | 4x DDR4 DIMM (128GB max, 4733MHz OC) |
Expansion Slots | 1x PCIe 4.0 x16, 1x PCIe 3.0 x1 |
Storage | 2x M.2 (PCIe 4.0/3.0), 4x SATA 6Gb/s |
USB | 4x USB 3.2 Gen1, 4x USB 2.0 |
Networking | Realtek 8118 Gaming GbE LAN |
Form Factor | Micro-ATX (24.4×24.4cm) |
🌟 Processor Support
- ⚡ AM4 Socket – Compatible with AMD Ryzen 3000/4000/5000 Series processors (BIOS update may be required for 5000 Series)
- 🧠 5+3 Phase VRM – Pure digital power solution with Low RDS(on) MOSFETs for stable performance
- 🔌 PCIe 4.0 Ready – Ultra durable x16 slot with reinforced design for high-end GPUs
❄️ Cooling & Memory
- 🌀 Smart Fan 5 – 3 hybrid fan headers with 5 temperature sensors for optimized cooling
- 🧊 DDR4 Support – Up to 128GB (4x32GB) at 4733MHz (OC), XMP profile support
- 🌡️ M.2 Thermal Guard – Heatsink for PCIe 4.0 M.2 slot to prevent throttling
🛠️ Expansion & Storage
- 💾 Dual M.2 Slots – PCIe 4.0 x4 (from CPU) + PCIe 3.0 x4 (from chipset) with SATA support
- 🔄 SATA Connectivity – 4x SATA 6Gb/s ports with RAID 0/1/10 support
- 🎮 PCIe 4.0 x16 – Armored slot for high-end graphics cards
🔌 Connectivity Features
- 📶 Rear I/O – HDMI 2.1, DVI-D, 4x USB 3.2 Gen1, 2x USB 2.0, LAN, audio jacks
- 💡 RGB Fusion 2.0 – 2x addressable LED headers + 3x RGB LED headers
- 🎧 High-End Audio – Realtek ALC887 with audio noise guard and premium capacitors
📦 Package Contents
- GIGABYTE B550M DS3H motherboard
- I/O shield
- 2x SATA cables
- User manual
- Driver disc
⚙️ Technical Specifications
Detail | Value |
---|---|
Audio Codec | Realtek ALC887 8-channel |
LAN Chip | Realtek 8118 Gaming GbE |
BIOS | 128Mb AMI UEFI |
Q-Flash Plus | BIOS update without CPU/RAM/GPU |
Warranty | 3 Years |
